ACS 300W Moving Head Beam Light

Description

ACS 300W LED Moving Head Beam Light

Powerful 300W LED Engine · Motorized Zoom · Dual Prisms & Pixel Ring

The ACS 300W LED Moving Head is a professional-grade fixture designed for maximum impact and versatility. At its core is a powerful 300W white LED engine, producing an exceptionally bright and sharp beam. This is enhanced by a wide motorized zoom ranging from a tight 3.8° to a broad 45°. The creative possibilities are endless with a 14-color wheel, a 14-pattern gobo wheel, and a dual-prism system (8-facet + 16-facet). A unique feature is the stunning RGB pixel ring with 40 controllable LEDs, perfect for creating mesmerizing eye-candy effects. With full DMX, master-slave, and auto modes, this light is a perfect solution for concert stages, large clubs, and professional lighting designers.

Key Features ▼

  • ✅ High-power 300W white LED engine for a bright, powerful beam
  • ✅ Wide motorized zoom, adjustable from a sharp 3.8° beam to a 45° wash
  • ✅ Dual rotatable prisms: an 8-facet and a 16-facet prism that can be layered
  • ✅ Dynamic effects with a 14-color wheel and a separate 14-pattern gobo wheel
  • ✅ Stunning RGB Pixel Ring with 40 controllable 5050 LEDs for eye-candy visuals
  • ✅ Professional control via DMX512 (24CH), Master-Slave, and Automatic modes
  • ✅ Advanced optics including motorized focus, linear frost, and 16-bit Pan/Tilt

Need help with advanced DMX programming or a quote for your event? Chat with our experts on WhatsApp.

Technical Specifications

Voltage AC100-240V, 50/60Hz
Total Power 450W
Main Light Source 300W White LED Module
Secondary Source 40 x 5050 RGB LEDs (Pixel Ring)
Beam Angle 3.8° - 45° (Motorized Zoom)
Control Mode DMX512 / Master-Slave / Auto / Sound Control
DMX Channels 24 Channels
Color Wheel 14 Colors + White
Gobo Wheel 14 Patterns + White
Prism 8-facet Prism + 16-facet Prism (Rotatable)
Movement Pan: 540°, Tilt: 270° (16-bit resolution)
Net Weight 12.4 kg


Important Notice

This fixture is rated IP20 for indoor use only. Avoid operating in humid or dusty environments. Ensure proper ventilation, especially around cooling fans, to maintain performance. Always use a safety cable when rigging overhead.

ACS 300W Moving Head Beam Light

Product form
$483.00

SKU: BCE-2582112

In stock - Shipped in 24 hours

    "Awesome"
    4.5/5 on
    • Direct from the Factory
    • Professional Technical Support
    • Customizable Solutions Available
      Why Choose ACS?

    1. Factory-Direct Pricing

    We cut out the middlemen so you get industrial-grade event gear at true factory prices — high quality, lower cost.

    2. Lifetime Support

    Our commitment doesn’t end after purchase. We provide lifetime technical support to help you get the most from your equipment, anytime you need it.

    3. Free & Reliable Global Delivery

    We ship worldwide with trusted carriers like DHL Express — always free, always trackable, and always reliable.

      Customer service

    We are listening to you from Monday to Saturday from 10 a.m. to 7 p.m.

    You can contact us via our contact form:

    Send us a message!

    Description

    ACS 300W LED Moving Head Beam Light

    Powerful 300W LED Engine · Motorized Zoom · Dual Prisms & Pixel Ring

    The ACS 300W LED Moving Head is a professional-grade fixture designed for maximum impact and versatility. At its core is a powerful 300W white LED engine, producing an exceptionally bright and sharp beam. This is enhanced by a wide motorized zoom ranging from a tight 3.8° to a broad 45°. The creative possibilities are endless with a 14-color wheel, a 14-pattern gobo wheel, and a dual-prism system (8-facet + 16-facet). A unique feature is the stunning RGB pixel ring with 40 controllable LEDs, perfect for creating mesmerizing eye-candy effects. With full DMX, master-slave, and auto modes, this light is a perfect solution for concert stages, large clubs, and professional lighting designers.

    Key Features ▼

    • ✅ High-power 300W white LED engine for a bright, powerful beam
    • ✅ Wide motorized zoom, adjustable from a sharp 3.8° beam to a 45° wash
    • ✅ Dual rotatable prisms: an 8-facet and a 16-facet prism that can be layered
    • ✅ Dynamic effects with a 14-color wheel and a separate 14-pattern gobo wheel
    • ✅ Stunning RGB Pixel Ring with 40 controllable 5050 LEDs for eye-candy visuals
    • ✅ Professional control via DMX512 (24CH), Master-Slave, and Automatic modes
    • ✅ Advanced optics including motorized focus, linear frost, and 16-bit Pan/Tilt

    Need help with advanced DMX programming or a quote for your event? Chat with our experts on WhatsApp.

    Technical Specifications

    Voltage AC100-240V, 50/60Hz
    Total Power 450W
    Main Light Source 300W White LED Module
    Secondary Source 40 x 5050 RGB LEDs (Pixel Ring)
    Beam Angle 3.8° - 45° (Motorized Zoom)
    Control Mode DMX512 / Master-Slave / Auto / Sound Control
    DMX Channels 24 Channels
    Color Wheel 14 Colors + White
    Gobo Wheel 14 Patterns + White
    Prism 8-facet Prism + 16-facet Prism (Rotatable)
    Movement Pan: 540°, Tilt: 270° (16-bit resolution)
    Net Weight 12.4 kg


    Important Notice

    This fixture is rated IP20 for indoor use only. Avoid operating in humid or dusty environments. Ensure proper ventilation, especially around cooling fans, to maintain performance. Always use a safety cable when rigging overhead.
