ACS CL-149 CO2 Big Confetti Machine DMX Control
300㎡ Area Coverage · Flight Case Packaging · 3m Hose Included
The ACS CL-149 is a high-powered DMX-controlled confetti machine with die-cast aluminum body and 3-meter high-pressure hose. Perfect for concerts, festivals, and large-scale shows, it can launch confetti up to 15 meters high and fill a 300 square meter area with flying color.
The built-in flight case design provides added durability and portability, while the stable structure ensures long service life. Designed for both indoor and outdoor events requiring maximum confetti impact.
Key Features ▼
- ✅ High Range: Fires confetti 10–15 meters high
- ✅ Large Capacity: Holds 30–40kg of confetti paper
- ✅ Durable Design: Die-cast aluminum with flight case body
- ✅ DMX Control: Works with professional consoles
- ✅ Coverage: Up to 300 square meters
Have questions about setup, logistics, or accessories? Contact us on WhatsApp for fast support and expert event guidance.
Technical Specifications
| Attribute |
Details |
| Voltage |
AC110V–240V 50–60Hz |
| Body Material |
Die-cast aluminum |
| Firing Height |
10–15 meters |
| Confetti Capacity |
30–40kg Paper |
| Package Type |
Flight Case |
| Control |
DMX |
| Hose Length |
3 meters |
| Area Coverage |
300 square meters |
| Warranty |
1 Year |
| Certification |
CE |
How To Use
- Install the confetti fan well and adjust the sprayer direction based on your setup.
- Connect the power and DMX cables. Serial connection available.
- Set the DMX address at the machine’s bottom.
- Ensure the air inlet is clean and not blocked.
- Add colored confetti into the cannon.
- Turn on power and activate via DMX controller.
Packing List
- ✓ 1 x CL-149 DMX Confetti Machine
- ✓ 1 x Power Cord
- ✓ 1 x DMX Cable
- ✓ 1 x 3m High-Pressure Hose
- ✓ 1 x Manual
Notice: Confetti paper sticks are not included. Please purchase them separately if needed.
Q&A
Q: What kind of activity would use a confetti blaster?
A: CL-149 is a perfect confetti blower to bring a shocking confetti rainbow effect for medium to large-size indoor and outdoor activities, such as cooperation events, sports events, and festivals.
Q: Could the pipe be customized in length? (Can make it longer?)
A: Sure, the pipe can be customized longer with extra pay for additional length.
Q: How long can CO2 pipe be used maximum?
A: It’s better not longer than 25 meters (80 feet) of pipe from a 40L tank. The machine does not have an effect if used over the length of a pipe or a small air-pressure CO2 tank.
Q: Can I link several CO2 cylinders to 1 confetti blaster?
A: You can connect multiple CO2 cylinders to one confetti blaster according to your needs.
Q: Can I connect 1 CO2 cylinder to several confetti blasters?
A: Generally one CO2 cylinder is connected with one confetti blaster, maximum to link two machines.
Q: How far is the confetti blaster CL-149 / CL-149-A / CL-150 spray confetti?
A: Confetti blaster CL-149 / CL-149-A spray confetti about 15m to 18m, and the mini model CL-150 sprays about 7m to 8m distance, on the base of enough air pressure of CO2 tank.
Q: What difference between CL-149-A and CL-149? Which one is better?
A: Both of them adopt the internal structure designed by the Venturi principle, which can make the colored paper vortex sprayed farther and higher when the gas passes through the machine. The difference is their control mode.
CL-149-A is manual use only, it needs to be done manually without a power supply.
CL-149 has two control ways, manual and DMX control. It needs to be connected to the power when working with the DMX console. In this way, multiple units can be connected to the console and used together, saving labor costs as well.
Q: How long can one 40L gas cylinder be used for a confetti blaster to spray confetti continuously?
A: A 40L cylinder can offer a maximum of 40 seconds to 1 machine for spraying continuous confetti shoots.
Q: Can small gas cylinders be placed inside the machine?
A: The 5L small gas cylinder can be placed in the slot in front of the CL-150, while the large machines CL-149 and CL-149-A do not have a space for the gas cylinder.
Q: Can I use powder in the confetti blaster?
A: Yes.
Q: What is the function of cast aluminum parts? Can I buy it separately?
A: The cast aluminum part is an internal structure design using the Venturi principle. It can make confetti paper spouted by vortexes farther and higher when the gas passes through the machine.
Sure you can buy it individually, but you must confirm whether the nozzle size of your existing machine fits with our cast aluminum part.
