ACS FX-10 350W 10M Flame Machine
350W Power · Up to 10M Spray Height · Waterproof · Dual Ignition
The ACS FX-10 is a high-powered, direct-injection flame machine designed for both indoor and outdoor use. Built for visual impact and reliability, it produces towering flames reaching up to 10 meters using isopropanol or isoalkane-based fuels. With a rugged stainless steel body and IPX3 waterproof protection, it performs even under rain and extreme conditions.
Featuring dual ignition, automatic tilt lock, and a safety mode switch, this unit provides unmatched safety and control. Ideal for festivals, concerts, outdoor celebrations, and permanent installations requiring maximum flame reach and consistency.
Key Features ▼
- ✅ Direct Fuel Injection: Liquid injection flame system with powerful visual output
- ✅ 8–10M Flame Height: Giant flame columns ideal for outdoor and stadium use
- ✅ Dual Ignition System: Improves ignition success and consistency
- ✅ IPX3 Waterproof: Operates safely even in light rain
- ✅ Tilt Protection: Auto nozzle lock when tilted ≥45°
- ✅ Safety Mode Lock: Switch between test and performance modes
- ✅ Stainless Steel Housing: Durable, rust-proof, and event-ready
Technical Specifications
| Attribute |
Details |
| Application |
Indoor / Outdoor |
| Voltage |
AC 100–240V |
| Power |
350W |
| Control Mode |
DMX512 |
| Waterproof Rating |
IPX3 |
| Fuel Type |
Isopropanol, Isoalkane G/H/L/M |
| Fuel Capacity |
5 Liters |
| Consumption Rate |
60ml / second |
| Spray Direction |
Vertically upward |
| Flame Height |
8–10 meters |
| Dimensions |
36 × 35 × 35 cm |
| Net Weight |
15.3kg (without fuel) |
How To Use
- Fill fuel tank with approved liquid fuel up to 5L.
- Connect DMX cable and power cord. Set DMX address.
- Switch to test mode for trial or to working mode for live performance.
- Activate safety lock, then trigger flame using DMX channels.
- After use, turn off power, release pressure, and safely store unit.
Packing List
- ✓ 1 x FX-10 Flame Machine
- ✓ 1 x Power Cable
- ✓ 1 x User Manual
- ✓ 1 x DMX Cable
Important Notice
Flame oil not included due to shipping restrictions. Always test in open and ventilated space with safety protocols in place.
Q&A
Q: Can this flame machine be used in the rain?
A: Yes, it is IPX3-rated for light rain. Still, avoid heavy storms for safety.
Q: What fuel can I use?
A: Use Isopropanol or Isoalkane G/H/L/M. Do not use gasoline or unknown liquids.
Q: Can I install it upside down or sideways?
A: No, spray direction must be vertical for safety and performance.
Q: How long does one full tank last?
A: Around 80–90 seconds of continuous spray (5L at 60ml/sec).
Q: What is the ignition success rate?
A: The dual ignition system provides high stability, close to 100% success under standard operation.
