ACS FX-5 Five Head DMX Flame Machine
DMX 512 · 3.2M Flame Height · 8 Channels · Safety Channel
The ACS FX-5 is a professional-grade flame machine featuring five independent flame heads, each controllable via DMX. Designed for stage productions, concerts, and outdoor events, it reaches a flame height of up to 3.2 meters with precise programmable sequences.
Equipped with an updated valve system, 5-pin DMX port, and a safety tilt shutoff, the FX-5 ensures high performance and peace of mind. With a 99% ignition success rate, this is a reliable tool for any serious event planner or production crew.
Key Features ▼
- ✅ 8 DMX Channels: Full control of each flame head + sequence effects
- ✅ 3.2M Flame Height: High-impact visuals for large-scale events
- ✅ Safety Channel: Prevents accidental firing during setup
- ✅ Dumping Device: Auto shutdown when tilted
- ✅ 5-Pin DMX: Professional-grade signal input with no delay
Technical Specifications
| Attribute |
Details |
| Voltage |
AC 100–120V / 200–240V 50-60Hz |
| Power |
210W |
| Flame Height |
Up to 3.2 meters |
| Control Mode |
DMX 512 |
| DMX Channels |
8 Channels |
| Net Weight |
16.77kg |
| Gross Weight |
18.66kg |
| Product Size |
53×31×43cm |
| Color |
Red (depends on flame oil) |
| Warranty |
1 year |
| Certification |
CE, RoHS, FCC |
Shipping
- Most of our products are in stock and will be processed within 1–5 business days.
- By default, we ship from China via DHL, FedEx, or UPS.
- Delivery time is usually 7–15 business days, depending on your location.
- A tracking number will be provided once your order is shipped.
- If you're looking for a better shipping rate, feel free to contact us via WhatsApp to switch to sea freight.
How To Use
- Install 5 bottles of flame oil into the holders and close the chamber door securely.
- Connect DMX and power cables. Power on and wait for DMX signal detection.
- Use DMX Channel 1 (value 100–150) to activate the safety channel.
- Use Channels 2–6 for individual flames, Channel 7 for all together, and Channel 8 for pattern sequences.
- Power off after use, disconnect cables, and wait 15 mins before removing oil.
Packing List
- ✓ 1 x FX-5 Flame Machine
- ✓ 1 x Power Cord
- ✓ 1 x DMX Cable
- ✓ 1 x User Manual
Important Notice
This product does not include DMX controller or flame oil. Please purchase separately.
Q&A
Q: Do I need DMX to operate this unit?
A: Yes. DMX controller is required for all functions.
Q: How many heads spray simultaneously?
A: You can control each of the 5 heads individually, or all together.
Q: What’s the spray height range?
A: Approximately 1–3.2 meters, depending on the flame fluid used.
Q: Can I customize flame color?
A: Yes, use colored flame oils for different effects.
Q: Is it safe for indoor events?
A: Only in large venues with proper ventilation and clearance. Always follow local fire safety rules.
